200W Laser Cleaning Machine For Weld Removal
200W Laser Cleaning Machine for Weld Removal
Product Introduction
Welding is a process widely used in metal fabrication. It involves the joining of two pieces of metal by melting and fusing them together. Welding many times leaves unwanted impurities on the surface, such as scale, rust, or oxide layers that need to be removed to ensure the quality of the final product. A 200W laser cleaning machine for weld removal can remove the impurities on the surface of a weld without damaging the material. The laser beam is a concentrated, high-energy beam of light that is aimed at the surface of the metal. The laser effectively vaporizes the impurities, without damaging the material.
The laser cleaning process is contactless and precise, allowing for the removal of impurities in hard-to-reach areas. The laser can also be used to selectively remove only the impurities, leaving the underlying material untouched. This makes it ideal for use on delicate or sensitive surfaces, such as those found in medical or aerospace applications.
Product Parameters
|
Model |
MRJ-FL-C200B |
Laser Power |
200W |
|
Pulse Energy |
1.5mJ |
Laser Wavelength |
1064nm |
|
Touch Screen |
7 inch |
Clean Head Weight |
0.7Kg |
|
Machine Weight |
120Kg |
Cleaning Modes |
8 patterns |
|
Cooling Method |
Air Cooling |
Operating Humidity |
10% to 80% |
|
Working Temperature |
0℃～45℃ |
Power Consumption |
800W 1200W |
|
Storage Temperature |
-10℃～60℃ |
Machine Size |
770*568*993mm |
|
Focal Length |
F=160mm/F=254mm(customizable) |
||
|
Cable Length |
5m (customizable,up to 8m) |
||
|
Input Power |
110-240VAC, 50/60Hz |
||
Laser cleaning machine can remove the welding seam and the specific operation process is as following:
- Preparation of equipment: purchase a 200W laser cleaning machine and accessories.
- preparation: clean the weld parts thoroughly ahead of time to ensure that the surface is free of impurities.
- Adjust the parameters: according to the material of the weld seam to choose the appropriate cleaning power and parameters.
- Start cleaning: the laser cleaning machine will be aimed at the weld part, press the start button to start cleaning.
- Move the laser head: cleaning according to the length of the weld to adjust the position of the laser head to ensure that the weld is cleaned.
- Check the cleaning effect: After the cleaning is complete, check the weld with an infrared camera to ensure that the surface is free of any dirt.
- Record data: Record the weld cleaning data to facilitate subsequent inspection and maintenance.
