20W Laser Etching Machine For Metal High Speed Laser Marking Machine

20W Laser Etching Machine For Metal High Speed Laser Marking Machine

Fiber lasers has advantages, they are mainly reflected in the fact follown: fiber lasers are waveguide-type structures that can tolerate strong pumping, with high gain, high conversion efficiency, low threshold;fiber laser has good output beam quality, narrow line width, simple structure, and high reliability.
Send Inquiry
Product Introduction

20W Laser Etching Machine for Metal High Speed


Product Features

◆ The 20W fiber etching system has high beam quality, fundamental mode output, perfect marking.

◆ This machine has high laser repetition frequency and stable output power, it can achieve high-speed marking and meet the requirements of fine marking.

◆ Our MRJ-Laser fiber laser engraving machine has strong environmental adaptability, can expand a lot of space, can cooperate with an assembly line.

◆ The stainless steel engraving machine uses full air-cooled design, maintenance-free, no consumables, small size, high reliability, high electro-optical conversion rate and long life.


Product Advantages

◆ This small laser marking machine is more compact, basically one person can complete the equipment handling. It can be moved to the desired location anytime and anywhere.This also means that we can take it to shopping malls, communities and other areas with a large number of people to carry out offline marketing promotion and earn the first bucket of gold for starting a business. Although the shape of the small laser marking machine "shrink", but the function is not compromised.

◆ MRJ-Laser optical fiber laser marking machine can be applied to iron, copper, aluminum, gold, silver and other metal materials, as well as PC, ABS, PVC, PC+ABS and other non-metallic materials.It can basically meet entrepreneurs' marking needs, such as mobile phone screen removal, cola can lettering, key chain, metal bookmark, metal nameplate marking, etc.


Product Details



Product Application

It can be used in electronic cigarettes, hardware products, medical packaging, wine packaging, building ceramics, beverage packaging, rubber products, shell nameplates, craft gifts, electronic components, leather, electronic components, integrated circuits (IC), electrical appliances, mobile phone communications, hardware products, tool accessories, precision instruments, glasses, watches, jewelry, automotive accessories, plastic keys, building materials, PVC pipes, medical devices, etc.


Samples

▼ Laser marking on watch

▼ Laser marking on daily necessities

20140711155390819081

20160718152833_20788

▼ Laser marking on instrument and components

ModelMRJ-FL-20BMRJ-FL-30BMRJ-FL-50B
Laser Power20W30W50W
Laser Wavelength1064nm1064nm1064nm
Beam QualityM2<1.6M2<1.6M2<2.0
Repetition Frequency20-80KHz30-80KHz50-120KHz
Marking Field300mmx300mm300mmx300mm300mmx300mm
Marking Depth≤1.2mm≤1.5mm2.0mm
Marking Line Speed≤14000mm/s≤14000mm/s≤14000mm/s
Minimum Line Width10um10um10um
Minimum Character0.15mm0.15mm0.15mm
Repetition Precision±0.005mm±0.005mm±0.005mm
Power Consumption≤600w≤800w1000w
Maintenance-free Time100000hours100000hours100000hours
Input PowerSingle Phase110VAC/220VAC/50-60Hz
Cooling MethodAir Cooling
